Rims
- Material: Maxtal
- Material: S6000 Aluminum
- Weight reduction: ISM
- E-Bike specific rim profile
- Tire: UST Tubeless and tubetype
- Internal width: 30 mm
- Black Shield treatment (protects your rim against impacts and scratches)
- ETRTO size 29": 622x30TC
- Pinch Flat Protection sidewall (minimizes the risk of tire cuts and punctures)
- Asymmetrical rim design
- ETRTO size 27.5": 584x30TC
- Fore, SUP

Spokes
- Material: steel
- Shape: straight pull, flat, double butted
- Nipples: Fore integrated aluminum
- Count: 28 front and rear
- Lacing: front and rear crossed 3, contactless

Hubs
- Hub available with 6-bolt or center lock (R) brake rotors
- Axles: Front 15X110 Boost ; Rear 12X148 Boost
Instant Drive 360
- QRM Auto

Versions
- Disc standard : 6 Bolts or Center Lock (R)
- Hub width : Boost only (front 110, rear 148)
- Freewheel: SRAM XD, Shimano HG9, Shimano - Micro-Spline

Compatibility
- Front axle: 15x110 Boost, convertible to 20x110 Boost thru axle with adapters
- Freewheel: Shimano HG9, XD or Micro Spline
- Rear axle: 12x148 Boost thru axle

Compatible Adapters
- Boost : 20x110 boost front hub cap ([LV2680400] - Delivered with the wheel)
- Boost : Torque Caps (LV2374400)
- ID360 Shimano HG9 alloy freewheel body (LV3780100)
- ID360 Shimano Micro Spline alloy freewheel body (LV3990100)
- ID360 Sram XD freewheel body (LV3740100)
- Boost 20mm : 20x110 boost front hub cap ([V2680401] - Not Delivered with the wheel, only compatible with INT6bolts hub)
